Comprehensive Technical Characteristics of Inverter
Input-output Characteristics:
Input Voltage Range: 380/220V±15%
Input Frequency Range: 47-63Hz
Output Voltage Range: 0-rated input voltage
Output Frequency Range: 0-400Hz
Peripheral Interface Characteristics
Programmable Digital Input: 6 channel input
Programmable Analog Input: 0-10V input, FI: 0-20mA or 4-20mA input
Open Collector Output: 1 channel output input
Relay Output: 1 channel output
Analog Output: 1 channel output, optional 0-20mA or 0-10V
Technical Performance Characteristics
Control Mode: SVC, V/F direct torque control
Overload Capacity: 150% rated current 60s; 180% rated current 10s
Starting Torque: SVC: 0.5Hz/150% (SVC)
Speed Regulation Ratio: SVC: 1:100
Speed Control Accuracy: SVC; ±0.5% maximum speed
Carrier Frequency: 0.5k-15.0kHz
